A few typos in 11be D0.2.
1. D0.2 PP244, ln 15, Equation 36-36. The last 0_23 highlighted in red circle is redundant. Note that this is correct in original SFD (1262r21 pp55).
SFD pp55:
The 4× 320 MHz EHT-LTF sequences are given as follows.
LTF320M_4x =
[ C(1)×LTF80M_4x_left, zeros(1,5), C(2)×LTF80M_4x_right, zeros(1,23), ...
C(3)×LTF80M_4x_left, zeros(1,5), C(4)×LTF80M_4x_right, zeros(1,23), ...
C(5)×LTF80M_4x_left, zeros(1,5), C(6)×LTF80M_4x_right, zeros(1,23), ...
C(7)×LTF80M_4x_left, zeros(1,5), C(8)×LTF80M_4x_right ];
2. D0.2 pp205, The BW field of the U-SIG, Set to 5 should be change to 320 MHz-2.
Same for D0.2, pp210.
Thanks.
Tianyu
