I would like to initiate discussion on P2P communication with EMLSR P2P Peer.
Thank you, Minyoung, Morteza, Pascal and Yong for the feedback during the presentation yesterday.
I would like to continue discussion with members interested in this issue.
Summary of the yesterday’s discussion is as follows.
[Minyoung] EMLSR P2P peer can operate in normal mode(not EMLSR mode) during the triggered TXOP sharing period since P2P communication is pre-scheduled. Because P2P communication operation is decoupled from a infrastructure operation, we don’t need to worry about infrastructure mode during P2P communication operation.
- AP MLD is able to know STA1’s P2P peers during P2P(TDLS) setup. AP MLD might know when STA1 will start P2P communication but AP can not know which is STA1’s P2P recipient since STA1 might have other P2P peers. I think P2P communication is not decoupled from infrastructure mode operation, P2P communication is more independent of infrastructure mode operation, which means a P2P STA can perform P2P communication at any time regardless whether the P2P STA is working with AP or not.
[Morteza] Peer STAs need to exchange control frames for EMLSR parameters such as transition delay.
- If STA is allowed to transmit ICT to EMLSR STA, EMLSR parameters exchange between STAs is required. As Pascal pointed out, another solution might be AP engagement. AP might be engaged to make EMLSR P2P STA operate in EMLSR operation. Once the direction is decided, EMLSR related procedure between STAs shall be considered.
[Pascal] AP can take an action for this case
- AP based solution is also possible. In r0 version, I proposed several options. I need some feedback which option is most preferable.
[Option 1] AP assisted mode change
[Option 2] New TXS mode (STA2 overhears MU-RTS TXS mode 3)
[Option 3] Allow a P2P sender to transmit ICF (same procedure in R1)
[Yong] AP can also transmit Data to STA2 at the same time.
- During the time(TXOP) shared with STA1, AP can not transmit data to STA2 since it's within AP’s TXOP and STA2 is also an associated STA.
Best Regards,
Ronny Yongho Kim
