Re: [STDS-802-11-TGBN] 回复: [STDS-802-11-TGBN] Updated P2P PDT



Hi Rubayet,

Thanks for your email. I got it. We may not need additional description of the setting for the Duration field of MU-RTS TXS TF, because it follows 11be. Although we have such a description in Co-TDMA.

Best regards,
Pei Zhou

TCL



Rubayet Shafin <r.shafin@xxxxxxxxxxx> 于2025年7月3日周四 13:38写道:

Hi Pei,



Thank you.



The TXSPG non-AP STA that is a member of the P2P group ignores the NAV itself. That TXSPG non-AP STA sets the Duration field in their transmitted frames during the allocated time so that the indicated NAV value is used by other STAs that are not members of the group to set those other STAs’ NAV following the baseline.



Sure, if this part still needs more clarification, we can do that in the text.



Best

Rubayet

From: zhoupei36@xxxxxxxxx <zhoupei36@xxxxxxxxx>
Sent: Wednesday, July 2, 2025 2:59 AM
To: Rubayet Shafin <r.shafin@xxxxxxxxxxx>
Cc: STDS-802-11-TGBN@xxxxxxxxxxxxxxxxx
Subject: 回复: [STDS-802-11-TGBN] 回复: [STDS-802-11-TGBN] Updated P2P PDT



Hi Rubayet,



Thanks for your clarification. I understand that the allocated TXOP duration can be protected by MU-RTS TXS TF and CTS.



Current text in your PDT is After sending the CTS , the TXSPG non-AP STA shall set the Duration/ID field of its following frames(s) to indicate a NAV end time that is no later than . I suppose it means that the TXSPG non-AP STA sets NAV to protect the allocated TXOP duration.

But before the TXSPG non-AP STA transmits its following frame(s), it may initiate an EDCA backoff procedure as stated in the previous email.



My suggestion is that we may add description about the Duration/ID field setting of MU-RTS TXS TF. Because it is not clear whether the EDCA backoff procedure is already protected.



Best regards,

Pei Zhou

TCL





发件人: Rubayet Shafin <r.shafin@xxxxxxxxxxx>
发送时间: 202572 15:11
收件人: zhoupei36@xxxxxxxxx; STDS-802-11-TGBN@xxxxxxxxxxxxxxxxx
主题: RE: [STDS-802-11-TGBN] 回复: [STDS-802-11-TGBN] Updated P2P PDT



Hi Pei,



Thank you very much for reviewing the document. Appreciate it.



A brief answer to your question is that TXSPG follows the baseline (11be) TXS procedure (35.2.1.2). Therefore, the entire duration of the TXOP allocated to the P2P group is protected by the NAV set by other users, derived from the MU-RTS TXS trigger frame sent by the AP. So the other STAs won’t be able to jump in, according to the baseline rules.



Elaborating a bit more-- when the Access Point (AP) transmits the MU-RTS TXS Trigger frame to the P2P group, this frame carries duration information. All STAs within the BSS that correctly receive this Trigger frame are required to update their intra-BSS NAV based on this duration. This prevents other STAs from attempting to transmit during this period, thereby protecting the allocated TXOP from external contention. Furthermore, a non-AP STA that is a member of the P2P addressed by the MU-RTS TXS Trigger frame shall transmit a Clear-to-Send (CTS) frame in response. This CTS frame, following the MU-RTS, further reinforces the NAV setting for any STAs that might not have heard the initial Trigger frame, thereby further extending the protection of the TXOP across the BSS.



Hope this clarifies. Please do not hesitate if you have any further comments or questions.



Best

Rubayet



From: Pei Zhou <zhoupei36@xxxxxxxxx>
Sent: Tuesday, July 1, 2025 4:55 AM
To: STDS-802-11-TGBN@xxxxxxxxxxxxxxxxx
Subject: [STDS-802-11-TGBN]
回复: [STDS-802-11-TGBN] Updated P2P PDT



Caution: This email originated from outside of the organization. Do not click links or open attachments unless you recognize the sender and know the content is safe.



Hi Jonghoe and Rubayet,



Thanks for sharing this P2P PDT. I have one comment regarding the 37.16.1.3 Non-AP STA behavior.



In the last paragraph of page 9, the non-AP STA may initiate an EDCA backoff procedure for the transmission of one or more non-TB PPDUs …”.

If non-AP STA use EDCA backoff procedure here, which means the channel may be idle for a while, so how to make sure that the current TXOP not be contended by other STAs?



Best regards,

Pei Zhou

TCL



发件人: Jonghoe Koo <jh89.koo@xxxxxxxxxxx>
发送时间: 2025630 20:59
收件人: STDS-802-11-TGBN@xxxxxxxxxxxxxxxxx
主题: Re: [STDS-802-11-TGBN] Updated P2P PDT



Hi Alfred,



Could you please indicate in the agenda that this document (P2P PDT doc 11-25/764) resolves 14 CIDs when adding it to the agenda?

The Abstract text box in the cover sheet of the uploaded document seems to be positioned in a way that obscures the list of CIDs that the document aims to address.



As attached, this document proposes resolutions for following 14 CIDs as part of CC50 comments:

229, 230, 849, 875 876, 1997, 2078, 2167, 2521, 2573, 3113, 3129, 3130, 3621





Dear all,



As shared by Rubayet and as described in the revision history of this document, we have made efforts to reflect as many technical comments as possible that we have received after the first version of the P2P PDT document was shared.

As part of these effort, numerous parts have been modified or removed.

We kindly request that members actively share your feedbacks on the revised contents as well, so that the document can undergo sufficient offline discussions and revisions before it is discussed.

Any editorial and/or technical comments would be greatly appreciated.



Regards,

Jonghoe KOO

Communications Standards Research Team, Samsung Research

Samsung Electronics



From: Rubayet Shafin <r.shafin@xxxxxxxxxxx>
Sent: Saturday, June 28, 2025 2:11 PM
To: STDS-802-11-TGBN@xxxxxxxxxxxxxxxxx
Subject: [STDS-802-11-TGBN] Updated P2P PDT



Hi Alfred,

Could you please add P2P PDT doc 11-25/764 to the MAC queue for SP?



Dear P2P TTTs,



Hope you all are doing well. I wanted to share some updates on the P2P PDT. Based on extensive discussions and feedback received from numerous members, either offline, online, or F2F (thanks to you all!), I have made significant changes to address the comments. One major change is that provisioning-related procedures have been entirely removed from the TXSPG for simplicity and ease of implementation. On the other hand, the Co-CR is now harmonized with the MAPC framework PDT. A summary of the changes is as follows—



TXSPG--

  • Removed the Provisioning part and all provisioning-related procedures/frames/elements
  • Added the MIB variable for TXSPG
  • Added an entry for the definition of TXSPG in clause 3.2
  • Removed Mode-3 based TXOP allocation procedure. Added text to reuse mode TXS Mode-2
  • Added that only AP can assign the Group ID.
  • Removed the new Direction field value (3—P2P group) in the QoS characteristics element; re-using value 2 (Direct Link)
  • Added that only the TXSPG requesting STA can send the SCS request for the P2P group;
  • Added that only the TXSPG requesting STA can return the TXOP
  • Added that TXSPG shall follow the TXS fairness rules introduced in 11bn for CTDMA
  • Changed the AID12 addressee to be the generic P2P group (AID12 = 2047);

Co-CR:

  • Harmonized the text with the MAPC framework PDT (11-25/599r16--Giovanni).
  • Moved to the subclause 37.13.2 (Procedures for specific multi-AP coordination schemes) the content of the detailed Co-CR operation between Co-CR requesting AP and Co-CR responding AP described in the subclause (Coordinated channel recommendation (Co-CR)) proposed by this document
  • As a part of Co-CR profile, specified the format of MAPC Per-Scheme Info field and the format of the Co-CR Parameter Set field that is contained in the MAPC Request Parameter Set field



The revised PDT can be found here and is also attached. I would appreciate it if you could review the document and let me know whether you have any comments on the revised PDT.



Best

Rubayet
