Hi Matt,

Thank you for the well written draft. Please find attached a few relatively minor comments. The only key point is that I would suggest to defer the text part regarding where NPCA Operation Information is carried and whether we have a NPCA Operation Information Present field or a NPCA Enabled field, till the UHR Operation Mode Update procedure by AP is finalized.

Regards,

Vishnu

From: Matthew Fischer <matthew.fischer@xxxxxxxxx>
Sent: Wednesday, June 18, 2025 10:05 PM
To: STDS-802-11-TGBN@xxxxxxxxxxxxxxxxx
Subject: Re: [STDS-802-11-TGBN] PDT CR MAC NPCA CC50 revision to document 11-25-936r6

Caution: This email originated from outside of the organization. Do not click links or open attachments unless you recognize the sender and know the content is safe.

Seongho,

Thanks for the comments.

Some responses:

1) During NPCA operation, successful PPDU transmissions/receptions are obviously a bonus time to utilize the momentarily empty resources. Therefore, it is very unreasonable for non-AP STAs to set the MU EDCA Timer due to UL TB PPDU transmission during NPCA operation while MU EDCA Timer is 0

I disagree.

The MUEDCA timer exists for the purpose of allowing a non-AP STA to perform untriggered UL TX when the AP is not providing enough triggers for UL to that STA.

Whether the AP grants a trigger for UL to a non-AP STA on channel A or channel B or channel C is completely immaterial to the discussion.

The only thing that the STA cares about is "Am I getting enough triggers?"

Therefore, I believe that the use of the MUEDCA timer across subchannels is completely appropriate.

NPCA provides more effective BW available for the AP to meet its commitments to the STAs by giving it more opportunities to transmit triggers to them.

2) If an NPCA non-AP STA successfully transmits any PPDU(s) including OM Control subfield with UL MU Disabled subfield set to 1 or UL MU Data Disable subfield set to 1, there no way to prevent untriggered UL transmission during NPCA operation for that STA. Am I correctly understanding

This seems to be correct.

MU EDCA has a philosophy of fairness for UL transmission, while NPCA uses it to achieve operational efficiency such as better coordination/management in the NPCA primary channel by blocking untriggered UL transmission. Since they have different purposes, I think it is more appropriate to separate the MAC variables related to MU EDCA Timer during NPCA operation from BSS primary channel

I disagree with the statement that MU EDCA exists to promote fairness.

MU EDCA exists to allow the AP to determine access according to its understanding of QoS objectives, and the result is very likely, unfair.

I do, however, agree that the use of MU EDCA in the NPCA channel is different from its use in the BSS primary channel.

Whether it is an appropriate use of MU EDCA is a different question and a much larger audience would need to voice its collective opinion before any change can be made.

This is a significant technical issue that cannot be addressed through a two-way dialogue.

If you have an alternative proposal, feel free to create a presentation and have it queued for discussion in the TG.

3) redundant phrase at the end of the MU EDCA parameters section

I agree, the phrase will be deleted.

4) better to use NPCA STA and NPCA peer STA?

I do not think it is better, as I see nothing wrong with saying first STA and second STA.

I.e. philosophically, don't fix something that is not broken

And if you change to "NPCA peer STA" then everyone will want a definition for that.

5) As mentioned in CID 787, if an NPCA STA (i.e., a first STA) is an NPCA AP, the NPCA AP shall not initiate a transmission during the longest switching delay among the switching delays of all NPCA non-AP STAs that are considered to be the recipients of the first ICF

Realized, based on this comment, that CID 787 did not have a resolution.

In response to the comment, I have added a "reject" resolution to CID 787.

The language already includes the possibility of mulitple recipients,so no change is needed.

6) what to do when an NPCA non-AP STA that is operating NPCA receives an ICF from its associated AP with the NPCA Primary channel Indication field not set (i.e., set to 0).

Agree.

New line added in the NPCA transmission section.

On Wed, Jun 18, 2025 at 6:11 AM 변성호 <sh.byeon@xxxxxxxxxxx> wrote:

Hi Matthew,

Thank you for continuously updating the CR.

I appreciate the nice work, and please find some comments in the attached.

Best Regards,

Seongho.

--------- Original Message ---------

Sender : Matthew Fischer <matthew.fischer@xxxxxxxxx>

Date : 2025-06-17 08:19 (GMT+9)

Title : [STDS-802-11-TGBN] PDT CR MAC NPCA CC50 revision to document 11-25-936r6

Revision 6 is now on the server:

Within the document, there is a revision notes section that summarizes the changes for each revision.

https://mentor.ieee.org/802.11/dcn/25/11-25-0936-06-00bn-pdt-cr-mac-npca-cc50.docx

--

Matthew Fischer

Broadcom
